LIFTHAND
HG Series Chain Hoist
Single or Dual speeds Hoist
Single or Dual speeds Trolley
Classification: 1Am
2 years warranty (excluding wearing parts)
NEMA Class F Motor
Magnetic Motor Brake
45% Duty Rating-3Phase
Limit Switch
Overload Protection (optional)
360° Swivel Forged Hook
IP65 Pendant Control
24V, 36V or 48V control
Remote Control (optional)
| Product Code | Capacity (t) | Lifting Speed(m/min) | Lifting Motor (kw) | Traversing Speed(m/min) | Traversing Motor (kw) | Load Chain(mm) | N.W. (kg) | I Beam (mm) | | ||
| 50HZ | 60HZ | 50HZ | 60HZ | | |||||||
| LHHG0.5-01S | 0.5 | 7.8 | 9.2 | 0.75 | 11 or 21 | 12 or 24 | 0.2 | φ6.3 | 45 | 70-130 | |
| LHHG0.5-01D | 7.8/2.6 | 9.2/3.0 | 0.75/0.25 | 0.2 | φ6.3 | 56 | 70-130 | | |||
| LHHG01-01S | 1 | 6.8 | 8.4 | 1.5 | 0.4 | φ7.1 | 65 | 80-160 | | ||
| LHHG01-01D | 7.2/2.4 | 8.4/2.8 | 1.5/0.5 | 0.4 | φ7.1 | 78 | 80-160 | | |||
| LHHG01-02S | 3.4 | 4.2 | 0.75 | 0.4 | φ6.3 | 56 | 80-160 | | |||
| LHHG01-02D | 3.9/1.3 | 4.2/1.4 | 0.75/0.25 | 0.4 | φ6.3 | 67 | 80-160 | | |||
| LHHG1.5-01S | 1.5 | 8.8 | 10.6 | 3.0 | 0.4 | φ10.0 | 112 | 82-178 | | ||
| LHHG1.5-01D | 8.8/2.9 | 10.6/3.4 | 4.0/1.5 | 0.4 | φ10.0 | 150 | 82-178 | | |||
| LHHG02-01S | 2 | 6.8 | 8.1 | 3.0 | 0.4 | φ10.0 | 121 | 82-178 | | ||
| LHHG02-01D | 6.8/2.3 | 8.1/2.7 | 4.0/1.5 | 0.4 | φ10.0 | 152 | 82-178 | | |||
| LHHG02-02S | 3.4 | 4 | 1.5 | 0.4 | φ7.1 | 80 | 82-178 | | |||
| LHHG02-02D | 3.6/1.2 | 4.0/1.3 | 1.5/0.5 | 0.4 | φ7.1 | 89 | 82-178 | | |||
| LHHG2.5-01S | 2.5 | 5.6 | 6.4 | 3.0 | 0.4 | φ11.2 | 124 | 100-180 | | ||
| LHHG2.5-01D | 5.6/1.8 | 6.4/2.1 | 4.0/1.5 | 0.4 | φ11.2 | 156 | 100-180 | | |||
| LHHG03-01S | 3 | 5.6 | 6.4 | 3.0 | 0.4 | φ11.2 | 129 | 100-180 | | ||
| LHHG03-01D | 5.6/1.8 | 6.4/2.1 | 4.0/1.5 | 0.4 | φ11.2 | 165 | 100-180 | | |||
| LHHG03-02S | 4.4 | 5.4 | 3.0 | 0.4 | φ10.0 | 138 | 100-180 | | |||
| LHHG03-02D | 4.4/1.5 | 5.4/1.8 | 4.0/1.5 | 0.4 | φ10.0 | 174 | 100-180 | | |||
| LHHG03-03S | 2.3 | 2.7 | 1.5 | 0.4 | φ7.1 | 92 | 100-180 | | |||
| LHHG03-03D | 2.4/0.8 | 2.7/0.9 | 1.5/0.5 | 0.4 | φ7.1 | 107 | 100-180 | | |||
| LHHG05-02S | 5 | 2.7 | 3.3 | 3.0 | 0.75 | φ11.2 | 154 | 110-180 | | ||
| LHHG05-02D | 2.7/0.9 | 3.3/1.1 | 4.0/1.5 | 0.75 | φ11.2 | 189 | 110-180 | | |||
| | | | | | | | | | | | |
